Product Description:
Steel Pipe 3-layer PE Internal External epoxy powder Coating
Machinery
It is an efficient method to make the epoxy powder of inside and outside the steel pipe for anti-corrosion. The anti corrosive steel pipe has many advantages, such as strong corrosion
resistance of the coating, which can resist the erosion of a
variety of chemical mediator; The coating surface is smooth and the friction resistance
is small. This steel pipe of anti corrosion is widely used in petroleum, natural gas transmission pipelines,
water supply and drainage pipelines and many other fields.
Applications:
Product Application Occasions and Scenarios:
- Manufacturing 3PE/3LPE/FBE Coated Steel Pipes for oil and gas
transportation
- Producing high-quality 3PE/3LPE/FBE Coated Steel Pipes for water
supply systems
- Creating coated pipes for corrosive chemical transport
- Suitable for Drip Irrigation Pipe Production Line
3PE can strengthen the pipeline's mechanical properties, high
electrical resistance, waterproof, wearable, anti-aging.
3PE coating/coated steel pipes are widely used in pipeline systems
for the transmission of oil, gas, water and other fluids. They have
highly resistance to corrosive from chemicals, moisture, harmful
environment etc.
Internal & External FBE Powder coating Structure Diagram
The epoxy powder is a kind of thermosetting nontoxic coating,
forming the high molecular weight cross-linking structure coating
after solidifying, featuring good chemical anticorrosion and higher
mechanical properties. The function of epoxy powder bottom layer is
to form continuous coating, providing excellent adhension by
agglutinate and solidifying the steel tube surface with good
chemical resistance and cathodic disbanding resistance. The
function of polymer adhesive is to agglutinate the epoxy powder
before gelation, and to agglutinate the polyethylene top layer,
which unites all three layers together.
Main equipment:| Item | Process Flow |
| 1 | Upload pipes |
| 2 | pipes sprial conveyor |
| 3 | external blasting |
| 4 | internal blasting |
| 5 | Rust removal |
| 6 | intermediate frequency heating |
| 7 | FBE powder coating |
| 8 | Powder recycling system |
| 9 | load down pipe rack |
Our Advantages:
-Adopt advanced technology
-Stable operation
-High degree of automation, saving labor costs
-Good anti-corrosion quality, meets international standard
-Supply full completed production solution: design, installation,
commissioning,training
-Share you 389 sets of production experience from all the world
-Having 9 professional senior engineers
-Having a high-end plastic machinery equipment expert workstation
in China
FAQ:
Q: What is the brand name of this 3LPE Coating Pipe Production
Line?
A: The brand name is Huashida.
Q: What is the model number of this production line?
A: The model number is 300-4200mm.
Q: What is Descaling grade?
A: SA2.5.
Q: What is Delivery Time?
A: 2-3monthes after deposit.
